Application
This DC surge protective device is applied low voltage standard IEC/EN 61643-11 to protect against DC powe line system and other equipment fromover voltage an instantaneous over voltage damage. Widely used ir photovoltaic comber box, power inverter,DC distributi or cabinet etc. It has advantages of large discharge current fast respond time, low residual voltage. Max. PV voltage up to Up≤1200V dc.
Main Features
1. High discharge capacity, quick response, module pluggable;
2. Fast response time, din rail installation;
3. Double thermal disconnection devices, provide more reliable protection;
4. Green window means normal, red means defect, need to change module;
5. Remote alarm terminal optional.
6. T2 surge protection.
Certificates
